j5create JCD3199 USB-C Dock Dual 4K HDMI – j5create International
| Model Name | j5create JCD3199 USB-C® Dock Dual 4K HDMI™ 140W Power Delivery 3.1 / 15W Wireless charger / Dual 4K HDMI™/ Gigabit Ethernet / USB™ 10Gbps Windows® / macOS® Compatible |
| Model | JCD3199 |
| Hardware | |
| Audio supported | Yes |
| Host connector | 1 – USB-C® Male (PD3.1 100W, 20V/5A) |
| Network interface | Yes |
| Output | Perfect for Google™ Pixel™, iPhone® with MagSafe®, and AirPods® – Provide 15W of wireless charging to a Google™ Pixel™ – Provide 7.5W of wireless charging to an iPhone® – Provide 5W of wireless charging to AirPods® |
| Ports | 1 – USB-C® PD-in PD3.1 140W (28V/5A) 2 – USB-C® 5Gbps & 10Gbps 2 – USB™ Type-A 5Gbps & 10Gbps 1 – Combo 3.5mm Audio Jack 1 – HDMI™ (USB™ display max resolution 4K@30Hz) 1 – HDMI™ (DP™-Alt max resolution 4K@60Hz) 1 – RJ45 Gigabit Ethernet 1 – SD™/microSD™ 3.0 1 – Wireless charger 15W |
| power source | Bus-powered or self-powered |
| video output | 2- HDMI™ Female |
| Performance | |
| audio channel | 2.1 via HDMI™ |
| compatible networks | 10/100/1000 Mbps |
| displays supported | 2 |
| max data transfer rate | 10Gbps |
| max display refresh rate | 60 Hz |
| max display resolution | 3840 x 2160 |
| Power | |
| input current | Up to 5A |
| input voltage | Up to 28V |
| output current | Up to 5A |
| output voltage | Up to 20V |
| power consumption | ≤ 900 mA |
| power delivery | Up to 140W via USB-C® |
| Physical Specifications | |
| cable length | 2.28 ft (69.5 cm) |
| color | Space Grey |
| enclosure type | Plastic |
| operating humidity | < 85% non-condensing |
| operating temperature | 30 to 116°F (-1 to 41°C) |
| product depth | Body: 5.12 in. (130 mm) Holder: 3.15 in. (80 mm) |
| product height | Body: 1.71 in. (43.5 mm) Holder: 1.3 in. (33 mm) |
| product weight | Body:14.7 oz (416 g) Holder:0.8 oz (22 g) |
| product width | Body: 5.12 in. (130 mm) Holder: 5.12 in. (130 mm) |
| storage humidity | < 85% non-condensing |
| Storage temperature | 0 to 155°F (-17 to 68°C) |
| Package Contents | 1 – JCD3199 USB-C® Dock Dual 4K HDMI™ 1 – Dock Holder 1 – Quick Installation Guide (QIG) |
Versatile 12-in-1 expansion, excellent companion for office
Easily add dual 4K display, extend your display area and maximize product
Break free from the limitation, effortlessly connect two additional displays to your M1/M2/M3 MacBook® or Windows® laptop
Integrates a wireless charger compatible with iPhone® MagSafe®, charge smart devices conveniently with up to 15W power
Exclusive PD 3.1 Power distribution technology ensures optimal PD 3.1 power utilization, even when used with computers supporting only PD 3.0
Supports a super-fast Gigabit network. Ensures a stable and dependable internet connection
Two USB™ 10Gbps and two USB™ 5Gbps ports for transferring data at ultra-high speeds and connect various peripherals
A built-in cable organizer for easy cable management
Includes a holder for vertical use, freeing up desk space for enhanced efficiency
Universal Compatibility
Support Windows® 11/10, macOS® 13/12/11, or later
Using with a PD 3.1 140W or higher charger is recommended for optimal performance
j5create JCD3199
- JCD3199 USB-C® Dock Dual 4K HDMI™
- 140W Power Delivery 3.1
- 15W Wireless charger
- Dual 4K HDMI™
- Gigabit Ethernet
- USB™ 10Gbps
- Windows® / macOS® Compatible
- Model: JCD3199
